Beidzot ari Latvijā - par pievilcīgām cenām

     Čehu ražotāja EPM  Profi line produkcija ar ražotāja 4         gadu garantiju.

 ____________________________________________________________________________

            Dreambox DM800HD

300 MHz MIPS Processor
- Linux Operating System
- OLED - Display
- MPEG-2 / H.264 Hardware decoding
- Tuner: DVB-S, optional: DVB-C, DVB-T
- Tuner Module, Plug&Play
- 1 x Smartcard-Reader
- V.24/RS232 Interface
- 10/100Mbit Ethernet Interface
- 1 x Scart (RGB, FBAS or S-Video)
- DVI
- 2 x USB 2.0
- analog modem
- S/PDIF Interface for digital bit stream out (AC-3)
- 64 MByte Flash, 256 MByte RAM
- SATA
  - for use either as internal SATA HDD 2,5“
  - or to use for extern eSATA

- unlimited channel lists for TV/Radio
- channel-change time < 1 second
- automatic service scan
- directly bouquet-lists
- EPG (electronic program guide)
- multiple LNB-Switching control (supports DiSEqC)
- OSD in many languages and skin-support
- Videotext Decoder
- extern 12V power supply

DreamBox DM800 technical data

DBS-Tuner mit DVB-S2:

Frequency Range 950 .... 2150 MHz
Demodulation DVB-S (QPSK); DVB-S2 (8PSK,QPSK)
Symbol rate DVB-S: 2 ... 45 Mbaud/s, SCPC/ MCPC
DVB-S2: 10 – 31 Mbaud/s (8PSK) , 10 –30 Mbaud/s (QPSK)

Video decoder:
Video Compression MPEG-2 and MPEG-1 compatible, H.246
Video Formats 4:3 / 16:9
Letterbox for 4:3 TV-Device

Audio decoder:
Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3
Audio Mode Dual (main/sub), Stereo
Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz

Output analog:
Output Level L/R 0,5 Vss on 600 Ohm
THD > 60 dB (1 kHz)
Crosstalk < -65 dB

Output digital:
Output Level 0,5 Vss on 75 Ohm
Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz
S/PDIF-Output optical, Toslink

Ausgang Video:
Ausgangspegel FBAS 1 Vss +/- 0.3 dB an 75 Ohm

Video parameter:
Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm
Teletext filter in conformity with ETS 300 472 Standard

TV-Scart:
Output: FBAS, RGB, S-Video

Serielle Interface RS 232:
Typ RS232 bidirectional
Bitrate 115,2 kBit/s max.
Plug Connector SUB-D-9
Function: Update of Firmware

Ethernet:
10/100 MBit compatible interface
Function: Update of Firmware

Analoge modem:
analoge modem for Internet connection

SATA Interface:
  - for use either as internal HDD 2,5“ or eSATAor internal 2,5" HDD

USB
2 x USB 2.0 Host

LNB power and polarisation per tuner:
LNB Current 500mA max.; short-circuit-protected
LNB Voltage vertical < 14V no load, > 11,5V at 400mA
LNB Voltage horizontal < 20V no load, > 17,3V at 400mA

Count of active satellite position:
DiSEqC 1.0/1.2 SAT POSITION / SAT OPTION
DiSEqC - Rotor Control

Power consumption:
< 15W at 12V

External PSU
Input:
110-240V AC / 50-60Hz / 0,6A
Output:
12V = / 3,0A

Physical specification:
Ambient Temperature +15°C...+35°C
Humidity < 80%
Size (W x D x H): 195 mm x 140 mm x 40 mm
Weight: 1,8 kg without HDD


 Mazumtirdzniecības cena  366,00 Ls/521 Eur

 ____________________________________________________________________________

        Kathrein UFS 910 HD

The Kathrein UFS 910 HD satellite receiver is quite a remarkable receiver, because of it's versatile capabilities as a Linux setopbox.

For the hobbyists amongst us this is a very interesting receiver, because it runs on Linux & has an Ethernet connector, so cardsharing is possible! There is already an alternative image available which can run cardsharing clients/SoftCAM emulators.
Sadly the specifications only mention DiSEqC 1.0 & not DiSEqC 1.2 which is required to drive a DiSEqC motor or a big DiSEqC swithc (>4 connections) Probably a future firmware upgrade will add DiSEqC 1.2 capability, because this only a software based feature.
The Kathrein UFS 910 HD receiver is available in black.
Specifications
• Reception of digital satellite TV and radio channels in the DVB-S & DVB-S2 transmission standards
• video decoding of MPEG-2 and MPEG-4/H.264 signals
• 16-digit alphanumeric display to show the channel names and programme information
• 4,000 channel memory positions
• Kathrein-easy-use EPG with timer programming
• Common Interface for two CA modules
• HDMI output for connection to an HDTV ready TV set
• HDCP copy protection
• Optical audio output for Dolby Digital data stream (AC 3)
• YPbPr output
• Cinch sockets for AV signal (composite colour picture, stereo-audio)
• One USB 2.0 port on the front panel & 2 USB 2.0 ports on the back panel for updates with a USB stic
• Multifunction setting device on the front panel
• Composite colour picture, RGB and Y/C signal output programmable on SCART socket
• Suitable for software updates (operational software & channel list separately) via satellite or USB stick.
• Language selection for programmes broadcast in several languages
• Channel search
• Channel position sort function
• Automatic date and time setting via DVB data stream
• On-screen display (OSD) in 8 languages (D, GB, F, I, E, CZ, NL, TR)
• DiSEqCTM 1.0 control signal and SCR one-cable system control signals (as of first quarter 2007)
• LINUX based operating system
• Mains switch
• Comes with: Remote control, batteries, manual, safety notes, SCART cable & power cable

    Mazumtirdzniecības cena
